Xerox WorkCentre 5020 System Administrator Guide

6 Printer Environment Settings
44
TCP/IP (LPD or Port9100) Environments
System configuration
As the machine supports the LPD and Port9100 protocol, you can print directly from a
Windows computer.
When printing from Windows 2000/Windows XP/Windows Server 2003/Windows Vista
computers through the LPD port, use the OS standard LPR port.
When printing through Port9100, change the necessary settings on the computers.
The transport protocol for LPD and Port9100 can be TCP/IP.
You will also need to set up the IP address on the machine and the Windows
computers. For information on how to set up an IP address, refer to
CentreWare
Internet Services Installation on page 24
.
TCP/IP (LPD or Port9100) Installation
This section describes how to set up the machine to use the LPD and Port9100
protocols.
Installation Procedure
There are three stages to enable printing on the machine through LPD or Port9100.
Network Communication Setup
Enable the following ports using the Control Panel or CentreWare Internet Services.
• Printing through LPD: LPD port
• Printing through Port9100: Port9100 port
Computer Setup
This requires the computers in the networking environment to be configured to
communicate with the machine.
Test Print
A print job should be submitted to make sure that the machine has been installed and
configured correctly.
Network Communication Setup
This section describes how to set up the network communication parameters of the
machine.
1. Confirm that an existing operational network utilizing TCP/IP is available.
2. Confirm that the machine is set up for CentreWare Internet Services.
NOTE: For information on the settings required to use CentreWare Internet Services,
refer to
CentreWare Internet Services Installation on page 24 .
3. Boot the LPD or Port9100 port using CentreWare Internet Services.
1) Open your web browser, and enter the machine's IP address in the [Address]
box to access CentreWare Internet Services.
2) Click the [Properties] tab.
3) Click the [Connectivity] folder, and then [Port Settings].

Xerox WorkCentre 5020 Specifications

General

Print Technology	Laser
Print Speed	Up to 20 ppm
Print Resolution	Up to 600 x 600 dpi
Max Paper Size	A3
Standard Paper Capacity	250 sheets
Bypass Tray Capacity	100 sheets
Duplex Printing	Manual
Copy Speed	Up to 20 cpm
First Page Out Time (Copying)	Less than 10 seconds
Scan Resolution	Up to 600 x 600 dpi
Operating System Compatibility	Windows, Mac OS
Automatic Document Feeder	50 sheets
Connectivity	USB 2.0
Functions	Print, Copy
Reduction / Enlargement	25% - 400%
Scan Destinations	USB, Email
Fax Transmission Speed	33.6 kbps
First Page Out Time (Printing)	Less than 8 seconds
