6885J11
6-24
9
8
7
6
5
4
3
2
1
Drive shaft and lower case
11. Insert a gear oil tube into the drain hole
and slowly fill the gear oil until oil flows
out of the check hole and no air bubbles
are visible.
NOTE:
To check the gear oil, refer to page 3-17.
12. Install the new gaskets t, check screw
y, drain screw u quickly, and then tight-
en to specified torque.
9. Place a block of wood between the anti-
cavitation plate and the propeller, and
then tighten the nut to the specified
torque.
w
9 Do not hold the propeller with your
hands when loosening or tightening it.
9 Be sure to disconnect the battery cables
from the battery and remove the lock
plate from the engine stop lanyard
switch.
9 Put a block of wood between the anti-
cavitation plate and propeller to prevent
the propeller from turning.
NOTE:
If the grooves in the propeller nut r do not
align with the propeller shaft hole, tighten the
nut until they are aligned.
10. Install a new cotter pin to the propeller
shaft.
Propeller nut r:
35 N·m (3.5 kgf·m, 25.8 ft·lb)
69D10050
y
t
u
t
Recommended gear oil:
Hypoid gear oil
API:GL-4
SAE: 90
Oil quantity:
610 cm
3
(20.62 US oz, 21.51 Imp oz)
Check screw y and drain screw u:
9 N·m (0.9 kgf·m, 6.6 ft·lb)
69R60285
