Yamaha F4A - Page 216

E
WATER PUMP
LOWR
EXPLODED DIAGRAM
View A
A
1
2
14
3
6
13
7
4
11
8
5
10
12
M6 x 45 mm
1st 3 Nm (0.3 m•kg, 2.17 ft•lb)
2nd 8 Nm (0.8 m•kg, 5.8 ft•lb)
M6 x 25 mm
13
9
1st 3 Nm (0.3 m•kg, 2.17 ft•lb)
2nd 8 Nm (0.8 m•kg, 5.8 ft•lb)
6-5
REMOVAL AND INSTALLATION CHART
Step
8
9
10
11
12
13
14
Q’ty
1
1
1
1
1
2
1
Service points
Reverse the removal steps for installation.
Not reusable
Procedure/Part name
Outer plate cartridge
Bolt (plate)
Plate
Shift rod boots
Lower casing packing
Dowel pin (plate)
Boots
