MOTIF XS6/MOTIF XS7/MOTIF XS8
122
OK
OK
08 :
Keyboard+AT
TEST
MOTIF XS Test Program
Scaling
OK
After Touch
AT Offset 1.556 v
OK
Displayed for XS8 only.
NG: No indication
[MIDI code output for judgment result]
OK: A0 09 02 <== (When all the keys and After Touch are
normal)
NG: No output
[How to quit test]
If all the keys are normally checked and indicated as OK, the test
will be completed and item selection condition will be selected.
If the judgment is NG on the way, refer to “D. How to carry
out tests when judged as NG
” (page 113) to proceed the
test program.
[Others]
None
T09: PB, MW, RB
(Test Code: A00A00)
Pitch Bend
(PB)
Modulation Wheel
(MW)
Ribbon Controller (RB)
(Touch volume)
[First indication]
Press
[ENTER]
09 :
PB, MW, RB
TEST
MOTIF XS Test Program
[Test contents]
Check that Pitch Bend (PB), Modulation Wheel (MW), and
Ribbon (RB) controller (Touch Volume) work normally.
Compare the PB, MW, RB value input from the EBUS A/D
input with the target values on the LCD.
[Test method]
According to an LCD indication as follows, operate controllers
In case of PB: 64(62 to
66)
"
127(126 to
127)
"
0(0 to
1)
Middle Up Down
Move smoothly in the order mentioned above.
In case of MW
: 0(0 to
1)
"
127(126 to
127)
Down Up
Move smoothly in the order mentioned above.
In case of RB: (0 to
15)
"
(90 to
112)
"
off(113 to
127)
Leftmost Rightmost Release
Slide the ribbon with your finger slowly and
then release.
The order of the controllers to be checked is not designated.
[Check item]
Check that the knobs are not stuck, values change smoothly and
that judgments are OK.
09 :
PB, MW, RB
TEST
MOTIF XS Test Program
yyy: Target value
xxx: Current value
Pitch Bend < yyy > xxx
Modulation Wheel < yyy > xxx
Ribbon Controller < yyy > xxx
[Judgment indication]
OK
