125
MOTIF XS6/MOTIF XS7/MOTIF XS8
[Others]
Take the following procedure to perform the test with MIDI
MODE.
The test is conducted using MIDI connectors, which indicates
that they are working normally, so it is not necessary to check
the [MIDI IN, OUT] connectors.
To check the [MIDI THRU] connector, send the MIDI code (AA
EF 00 55) to the [MIDI IN] connector when the unit is not in
test mode and check if the same MIDI code is transmitted from
the [MIDI THRU] connector.
Reference: The code may be shown as (EF 00 55) on the
display.
T12: USB(to DEVICE)
(Test Code: A00C00)
[First indication]
Press
[ENTER]
12 :
USB (to DEVICE)
TEST
MOTIF XS Test Program
[Test contents]
Check that the [USB TO DEVICE] connector works normally.
Checks if the connected device is recognized.
(Checks via USB Host Controller if USB Memory (USB 2.0
compatible) is connected.)
[Testmethod]
Press the [ENTER] when the first indication is shown and
the following indication will be shown. Then, insert a USB
memory into the [USB TO DEVICE] connector.
Press the [ENTER] button again to execute the test.
12 :
USB (to DEVICE)
TEST
MOTIF XS Test Program
Insert USB Memory! and
Press [
ENTER
]
[Check item]
Check that the USB Memory is recognized.
[Judgment indication]
OK
OK
12 :
USB (to DEVICE)
TEST
MOTIF XS Test Program
Example of an NG
NG
12 :
USB (to DEVICE)
TEST
MOTIF XS Test Program
[MIDI code output for judgment result]
OK: A0 0C 02 <==
NG: A0 0C 03 <==
[How to quit test]
The judgment is shown, the test will be completed and item
selection condition will be selected.
[Others]
None
