MOTIF XS6/MOTIF XS7/MOTIF XS8
T14: 1 KHz OUTPUT L
(Test Code: A00E00)
[First indication]
Press
[ENTER]
14 :
OUTPUT-L
TEST
MOTIF XS Test Program
[Test contents]
Check that normal signals are output from the [OUTPUT
L/MONO], [ASSIGNABLE OUTPUT L] and [PHONES(L)]
jacks.
Operate the [MASTER VOLUME] to check that volume
from the [OUTPUT L/MONO] is changed smoothly.
(Play the sine wave of the Wave ROM from the Master side
SWP51(DM: IC010) to output from the specifi ed output jack.)
[Test method]
Connect measuring instruments to each of the [OUTPUT L/
MONO], [OUTPUT R], [ASSIGNABLE OUTPUT L, R] and
[PHONES(L),(R)] jacks. Check frequency, output waveform,
output level of each output with a frequency counter, oscilloscope
and level meter (with a JIS-C fi lter).
Set the [MASTER VOLUME] at the maximum.
The LCD displays as follows when a sound is output.
ON
14 :
OUTPUT-L
TEST
MOTIF XS Test Program
[Check item]
[OUTPUT L/MONO]: 1 KHz±1.5 Hz, Sine wave, +5.0±2 dBu
(10 kohm load) (Distortion factor of
0.1 % or less)
Operate the [MASTER VOLUME] knob
to check that volume from the [OUTPUT
L/MONO] is changed smoothly.
[OUTPUT R]: -85.0 dBu or less (10 kohm load)
[ASSIGNABLE OUTPUT L]:
1 KHz±1.5 Hz, Sine wave, +4.0±2 dBu
(10 kohm load) (Distortion factor of
0.1 % or less)
[ASSIGNABLE OUTPUT R]:
-85.0 dBu or less (10 kohm load)
[PHONES(L)]: 1 KHz±1.5 Hz, Sine wave, -2.0±2 dBu
(33 ohm load) (Distortion factor of 0.1
% or less)
[PHONES(R)]: -70.0 dBu or less (33 ohm load)
[DIGITAL OUT(L)]: Output sound from a powered monitor
speaker with digital input and check that
sine wave without distortion is output.
[Judgment indication]
OK: No indication
NG: No indication
[MIDI code output for judgment result]
None
[How to quit test]
• MANUAL MODE:
Press the [EXIT] button to quit the test and the same screen as
the [First indication] will appear indicating that a condition
waiting for a test number is selected.
• MIDI MODE:
Send a test code for another test to complete the current test
and the test for the newly sent test code will be executed.
[Others]
None
T15: 1 KHz OUTPUT R
(Test Code: A00F00)
[First indication]
Press
[ENTER]
15 :
OUTPUT-R
TEST
MOTIF XS Test Program
[Test contents]
Check that normal signals are output from the [OUTPUT R],
[ASSIGNABLE OUTPUT R] and [PHONES (R)] jacks.
To Next Page
