MOTIF XS6/MOTIF XS7/MOTIF XS8
126
T13: USB(to HOST)
(Test Code: A00D00)
[First indication]
Press
[ENTER]
13 :
USB (to HOST)
TEST
MOTIF XS Test Program
[Test contents]
Check that the [USB TO HOST] connector works normally.
Connect the [USB TO DEVICE] connector with the [USB
TO HOST] connector and check operation.
Check via USB Host Controller if MOTIF XS is connected
or not.
[Test method]
When the first indication is displayed, press the [ENTER]
button. Check that “Connect USB!” is displayed and then
connect the [USB TO DEVICE] connector and the [USB TO
HOST] with a USB cable (A-B Type). Then, press the [ENTER]
button to execute the test.
13 :
USB (to HOST)
TEST
MOTIF XS Test Program
Connect USB!
[Check item]
Check that the MOTIF XS is recognized.
[Judgment indication]
OK
OK
13 :
USB (to HOST)
TEST
MOTIF XS Test Program
Example of an NG
NG
13 :
USB (to HOST)
TEST
MOTIF XS Test Program
[MIDI code output for judgment result]
OK: A0 0D 02 <==
NG: A0 0D 03 <==
[How to quit test]
The judgment is shown, the test will be completed and item
selection condition will be selected.
[Others]
None
