Yamaha Motif XS Series User Manual

MOTIF XS6/MOTIF XS7/MOTIF XS8
132
Data for each ROM are loaded from specifi c address group
and is compared with the specifi ed values.
[Test method]
Executes the test.
[Check item]
Check the test result on the LCD.
[Judgment indication]
OK
20 : ROM
TEST
MOTIF XS Test Program
OK
SYSTEM ROM
IC515
WAVE ROM
IC715 L1
L2
OK OK
OK
IC716 H1
H2
OK
OK
Example of an NG
20 : ROM
TEST
MOTIF XS Test Program
NG
SYSTEM ROM
IC515
WAVE ROM
IC715 L1
L2
OK OK
NG
IC716 H1
H2
OK
OK
[MIDI code output for judgment result]
OK: A0 1B 02 <==
NG: A0 1B 03 <==
[How to quit test]
When the judgment is shown and output, the test will be
completed and item selection condition will be selected.
[Others]
None
T21: RAM R/W
(Test Code: A01C00)
[First indication]
[Test contents]
Executes Write/Read/Verify test of the MAIN CPU and SDRAM
for Effect.
DM: IC201 (DDR-RAM high 16-Bit side),
IC202 (DDR-RAM low 16-Bit side)
DM: IC602 (SWP51 Master Effect),
IC601 (SWP51 Slave Effect)
Specifi c data are written to the specifi ed address group and
the data are loaded and compared with the written data.
[Test method]
Executes the test.
[Check item]
Check the test result on the LCD.
[Judgment indication]
OK
Press [ENTER] 21 : RAM
TEST
MOTIF XS Test Program
21 : RAM
TEST
MOTIF XS Test Program
OK
IC201
OK
IC202 OK
IC601 OK
IC602 OK

Yamaha Motif XS Series Specifications

General

Type	Workstation Synthesizer
Sound Engine	AWM2 with Expanded Articulation
Polyphony	128 notes
Wave ROM	355MB (when converted to 16-bit linear format)
Arpeggiator	6, 000 types
Effects	Reverb, chorus, part EQ
Sequencer	16-track sequencer, 130, 000 notes
Display	320 x 240 dot backlit LCD
Connectivity	USB, MIDI In/Out/Thru
Storage	USB storage device support
Keyboard	88-key (Motif XS8), 76-key (Motif XS7), 61-key (Motif XS6)
Number of Voices	1, 024 normal voices + 64 drum kits
