Yamaha Motif XS Series User Manual

135
MOTIF XS6/MOTIF XS7/MOTIF XS8
T23: Ethernet
(Test Code: A02000)
[First indication]
Press [ENTER] 23 : Ethernet
TEST
MOTIF XS Test Program
[Test contents]
Connect to a wired LAN router with an Ethernet cable (LAN
cable).
[Test method]
Executes the test. (It will take about 15 seconds for the test.)
[Check item]
Check the test result on the LCD.
[Judgment indication]
OK
OK 23 : Ethernet
TEST
MOTIF XS Test Program
Example of an NG
NG 23 : Ethernet
TEST
MOTIF XS Test Program
[MIDI code output for judgment result]
OK: A0 20 02 <==
NG: A0 20 03 <==
[How to quit test]
When the judgment is shown and output, the test will be
completed and item selection condition will be selected.
[Others]
None
T24: Factory Set
(Test Code: A01E00)
[First indication]
Press [ENTER] 24 : FactorySet
TEST
MOTIF XS Test Program
[Test contents]
Reset to the factory default settings.
Write initial values for each parameter on the SDRAM and
then write the data onto the Flash ROM.
[Test method]
Executes the test. (It will take about 10 seconds for the test.)
When the test is fi nished normally, a sine wave will be played
for a while.
[Check item]
None

Yamaha Motif XS Series Specifications

General

Type	Workstation Synthesizer
Sound Engine	AWM2 with Expanded Articulation
Polyphony	128 notes
Wave ROM	355MB (when converted to 16-bit linear format)
Arpeggiator	6, 000 types
Effects	Reverb, chorus, part EQ
Sequencer	16-track sequencer, 130, 000 notes
Display	320 x 240 dot backlit LCD
Connectivity	USB, MIDI In/Out/Thru
Storage	USB storage device support
Keyboard	88-key (Motif XS8), 76-key (Motif XS7), 61-key (Motif XS6)
Number of Voices	1, 024 normal voices + 64 drum kits
