Yamaha Motif XS Series User Manual

MOTIF XS6/MOTIF XS7/MOTIF XS8
184
(2) RECEIVE FLOW
Hn8FFOETON---------+--]9WS[-+->IDIM
||
| Hn9FFO/NOETON---------+
| |
| +---------KEY'S AFTER TOUCH AnH (Seq only)
||
| +---------CONTROL CHANGE (All in Seq)
H10,HnBNOITALUDOM||
| | PORTAMENTO TIME BnH, 05H
| | DATA ENTRY MSB BnH, 06H
| | DATA ENTRY LSB BnH, 26H
| | CHANNEL VOLUME BnH, 07H
HA0,HnBNAP||
HB0,HnBN
OISSERPXE||
H04,HnBHCTIWSNIATSUS||
| | PORTAMENTO SWITCH BnH, 41H
H24,HnBOTUNETSOS||
| | HARMONIC CONTENT BnH, 47H
| | EG RELEASE TIME BnH, 48H
H94,HnBEMITKCATTAGE||
HA4,HnBSSENTHGIRB||
HB4,HnBE
MITYACEDGE||
| | EFFECTS 1 DEPTH BnH, 5BH
| | EFFECTS 3 DEPTH BnH, 5DH
H06,HnBCNIYRTNEATAD||
H16,HnBCEDYRTNEATAD||
H87,HnBFFODNUOSLLA||
| | ASSIGNABLE CONTROLLER BnH, (00H .. 5FH)
| | RPN
| | PITCH BEND SENS.
BnH, 64H, 00H, 65H, 00H, 06H, mmH
| | FINE TUNING BnH, 64H, 01H, 65H, 00H, 06H,
1*Hll,H62,Hmm||
| | COARSE TUNING BnH, 64H, 02H, 65H, 00H, 06H,
1*Hmm||
HF7,H56,HF7,H46,HnBTESERNPR||
||
H00,HnBBSMLESKNAB--]6WS[--+|
H02,HnBBSLLESKNAB||
||
| +---------CHANNEL MODE MESSAGE
| | RESET ALL CONTROLLERS BnH, 79H
HC7,HnBFFOEDOMINMO||
HD7,HnBNOEDOMINMO||
HE7,HnBNOEDOMONOM||
HF7,HnBNOEDOMYLOP||
||
HnCEGNAHCMARGORP--]7
WS[--+|
||
| +---------CHANNEL AFTER TOUCH DnH
||
| +---------PITCH BEND CHANGE EnH
|
+--[SW2]-----------SYSTEM COMMON MESSAGE
| MTC QUARTER FRAME MESSAGE F1H
|
+--[SW3]-----------SYSTEM COMMON MESSAGE
H2FRETNIOPNOITISOPGNOS|
H3FTCELESGNOS|
|
+--[SW2]-----------SYSTEM REALTIME MESSAGE
H8FKCOLCGNIMIT|
|
+--[SW3]-----------SYSTEM REALTIME MESSAGE
HAFTRATS|
HBFEUNITNOC|
HCFPOTS|
|
+------------------ACTIVE SENSINGFEH
|
+--[SW4]-+---------SYSTEM EXCLUSIVE MESSAGE (All in Seq)
| | MIDI MASTER VOLUME F0H 7FH 7FH 04H 01H llH mmH F7H
||
| +--[SW8]---<BULK DUMP>
| | F0H 43H 0nH 7FH 03H bhH blH ahH amH alH ddH....ddH ccH F7H
||
| +--[SW5]---<PARAMETER CHANGE>
| | F0H 43H 1nH 7FH 03H ahH amH alH ddH.....ddH F7H
||
| +--[SW5]---<BULK DUMP REQUEST>
| | F0H 43H 2nH 7FH 03H ahH amH alH ddH.....ddH F7H
||
| +--[SW5]---<PARAMETER REQUEST>
| | F0H 43H 3nH 7FH 03H ahH amH alH F7H
||
| +----------GM MODE ON
| F0H 7EH 7FH 09H 01H F7H
|
+------------------SYSTEM EXCLUSIVE MESSAGE
IDENTITY REQUEST F0H 7EH 0nH 06H 01H F7H
[SW2] MIDI Sync (can be set to “internal,” “MIDI,” or “MTC.”)
[SW3] Seq MIDI Control
[SW4] MIDI Device Number
When this is not set to off, the MIDI Master Volume can be recognized in any mode.
The sequence data played back in the Song/Pattern mode is transmitted according to the MIDI Filter settings.
[SW5] The Edit Buffer data of a mode can be recognized in only the current mode.
The other types of data can be transmitted/recognized in any mode.
[SW6] SYSTEM Bank Select Switch
[SW7] SYSTEM Program Change Switch (This parameter can be received only in the Voice Play mode.)
[SW8] SYSTEM Bulk Protect and same as SW6.
[SW9] MIDI Receive Channel and Receive Filter
In the Song/Pattern mode: complies with Part Receive Channel and Part Receive Switch.
In the other mode: complies with Basic Receive Channel.
The sequence data recorded to the Song/Pattern is recognized according to the MIDI Filter settings.
(3) TRANSMIT/RECEIVE DATA
(3-1) CHANNEL VOICE MESSAGES
(3-1-1) NOTE OFF
STATUS 1000nnnn (8nH) n = 0 - 15 CHANNEL NUMBER
NOTE No. 0kkkkkkk k = 0 (C-2) - 127 (G8)
VELOCITY 0vvvvvvv v: ignored
Receive only
(3-1-2) NOTE ON/OFF
STATUS 1001nnnn (9nH) n = 0 - 15 CHANNEL NUMBER
)8G(721-)2-C(0=kkkkkkkk0REBMUNETON
VELOCITY NOTE ON 0vvvvvvv (v≠0)
NOTE OFF 0vvvvvvv (v=0)
(3-1-3) CONTROL CHANGE
STATUS 1011nnnn (BnH) n = 0 - 15 CHANNEL NUMBER
CONTROL NUMBER 0ccccccc
CONTROL VALUE 0vvvvvvv
*TRANSMITTED CONTROL NUMBER
c = 0 BANK SEL MSB ; v = 0 - 127
3*721-0=v;BSLLESKNAB23=c
3*721-0=v;NOITALUDOM1=c
c = 7 CHANNEL VOLUME ; v = 0 - 127
721-0=v;NAP01=c
c = 11 EXPRESSION ; v = 0 - 127
c = 64 SUSTAIN SWITCH ; v = 0, 127
c = 71 FILTER RESONANCE ; v = 0: -64 - 64: 0 - 127: +63
c = 72 EG RELEASE TIME ; v = 0: -64 - 64: 0 - 127: +63
c = 73 EG ATTACK TIME ; v = 0: -64 - 64: 0 - 127: +63
c = 74 FILTER CUTOFF FREQ ; v = 0: -64 - 64: 0 - 127: +63
c = 75 EG DECAY TIME ; v = 0: -64 - 64: 0 - 127: +63
c = 91 REVERB SEND ; v = 0, 127
c = 93 CHORUS SEND ; v = 0, 127
c = 0..95 ASSIGNABLE CONTROLLERS ; v = 0 - 127
The Sequencer Part will play back all recorded control change messages.
* RECEIVED CONTROL NUMBER
3*721-0=v;BSMLESKNAB0=c
3*721
-0=v;BSLLESKNAB23=c
c = 1 MODULATION ; v = 0 - 127
2*721-0=v;EMITOTNEMATROP5=c
1*721-0=v;BSMYRTNEATAD6=c
1*721-0=v;BSLYRTNEATAD83=c
c = 7 MAIN VOLUME ; v = 0 - 127
72
1-0=v;NAP01=c
c = 11 EXPRESSION ; v = 0 - 127
c = 64 SUSTAIN SWITCH ; v = 0 - 63: OFF, 64 - 127: ON *2
c = 65 PORTAMENTO SWITCH ; v = 0 - 63: OFF, 64 - 127: ON *2
c = 66 SOSTENUTO ; v = 0 - 63: OFF, 64 - 127: ON *2
c = 71 HARMONIC CONTENT ; v = 0: -64 - 64: 0 - 127: +63
c = 72 EG RELEASE TIME ; v = 0: -64 - 64: 0 - 127: +63 *2
c = 73 EG ATTACK TIME ; v = 0: -64 - 64: 0 - 127: +63
c = 74 BRIGHTNESS ; v = 0: -64 - 64: 0 - 127: +63
c = 75 EG DECAY TIME ; v = 0: -64 - 64: 0 - 127: +63
c = 91 EFFECTS 1 DEPTH ; v = 0 - 127
c = 93 EFFECTS 3 DEPTH ; v = 0 - 127
1*721=v;CNIYRTNEATAD69=c
1*721=v;CEDYRTNEATAD79=c
4*721-0=v;RELLORTNOCELBANGISSA59..0=
c
c = 0..95 ARPEGGIO SW ; v = 0-63: OFF, 64-127: ON *4
c = 0..95 ARPEGGIO HOLD ; v = 0-63: OFF, 64-127: ON *4
All Control Change events can be recorded to the song/pattern.
*1 Used only when a value is set using RPN.
*2 Invalid with Drum Voices.
*3 Relation between BANK CHANGE and PROGRAM is as follows:
*4 The default CONTROL NUMBERs of ASSIGNABLE CONTROLLER are as follows:
BREATH CONTROLLER 2
FOOT CONTROLLER 4
611ngissA
712ngissA
Assignable Function Button 1 86
Assignable Function Button 2 87
FOOT SWITCH 88
*5 Can be selected only in the Song/Pattern mode. Up to 128 Sample Voices are available in a Song/Pattern.
*6 Can be selected only in the Song/Pattern mode. Up to 16 Mixing Voices are available in a Song/Pattern.
CATEGORY MSB LSB PROGRAM No.
GM Voice 0 0 0..127 (1..128)
GM Drum Voice 127 0 0 (1)
Normal Voice Preset 1 63 0 0..127 (1..128)
Preset 2 63 1 0..127 (1..128)
Preset 3 63 2 0..127 (1..128)
Preset 4 63 3 0..127 (1..128)
Preset 5 63 4 0..127 (1..128)
Preset 6 63 5 0..127 (1..128)
Preset 7 63 6 0..127 (1..128)
Preset 8 63 7 0..127 (1..128)
User 1 63 8 0..127 (1..128)
User 2 63 9 0..127 (1..128)
User 3 63 10 0..127 (1..128)
Drum Voice Preset 63 32 0..63 (1..64)
Drum Voice User 63 40 0..31 (1..32)
Performance User 1 63 64 0..127 (1..128)
Performance User 2 63 65 0..127 (1..128)
Performance User 3 63 66 0..127 (1..128)
Sample Voice 63 50 0..127 (1..128) *5
Mixing Voice 63 60 0..15 (1..16) *6

Yamaha Motif XS Series Specifications

General

Type	Workstation Synthesizer
Sound Engine	AWM2 with Expanded Articulation
Polyphony	128 notes
Wave ROM	355MB (when converted to 16-bit linear format)
Arpeggiator	6, 000 types
Effects	Reverb, chorus, part EQ
Sequencer	16-track sequencer, 130, 000 notes
Display	320 x 240 dot backlit LCD
Connectivity	USB, MIDI In/Out/Thru
Storage	USB storage device support
Keyboard	88-key (Motif XS8), 76-key (Motif XS7), 61-key (Motif XS6)
Number of Voices	1, 024 normal voices + 64 drum kits
