YASKAWA SGDA series User Manual

USING THE DIGITAL OPERATOR
4.1.4 Operation in Status Display Modecont.
172
Bit Data Description
Power ON Lit when Servopack power ON. Not lit when Servopack
power OFF.
Base Block Lit for base block. Not lit at servo ON.
Speed Coincidence Lit if motor speed reaches speed reference. Otherwise,
not lit.
TGON or Torque Limit Detected
(selected by Cn-01 Bit 4)
Lit if motor speed exceeds preset value.
Not lit if motor speed is below preset value.
Preset value: Set in Cn-0B (20 r/min is factory setting)
Lit if Servopack internal torque reference exceeds preset
value.
Not lit if Servopack internal torque reference is below
preset value.
Preset value: Set in Cn-08, -09 (max. torque is standard
setting)
Cn-18 is preset value during 1CN-11 (P-CL
) input.
Cn-19 is preset value during 1CN-12 (N-CL
) input.
Not lit during torque control.
Speed Reference Input Lit if input speed reference exceeds preset value.
Not lit if input speed reference is below preset value.
Specified value: Set in Cn-0B (20 r/min is factory setting)
Torque Reference Input Lit if input torque reference exceeds preset value.
Not lit if input torque reference is below preset value.
Preset value: Set in Cn-0B (10% rated torque is standard
setting)
4
