SERVO SELECTION AND DATA SHEETS
5.6.3 Connector Kitscont.
316
4) Only one type of encoder connector is available for the Servopack end of the cable.
• Connector
Pin #1
Pin # 11
(0.10)
(0.05)
2.3(0.09)
5.1(0.20)
(0.05)
(0.50)
(0.11)
(0.26)
(0.76)
(0.36)
(0.30)
Units: mm (inches)
Connector Type A B C
10120-3000VE 11.43(0.45) 17.6(0.69) 22.0(0.87)
