YASKAWA SGDA series User Manual

SERVO SELECTION AND DATA SHEETS
5.6.5 Encoder Cablescont.
324
Type L in mm (feet)
DP8409123-1
3000
+100
0
(10
+0.33
0
)
DP8409123-2
5000
+100
0
(16.7
+0.33
0
)
DP8409123-3
10000
+500
0
(33.3
+1.67
0
)
DP8409123-4
15000
+500
0
(50
+1.67
0
)
DP8409123-5
20000
+500
0
(66.7
+1.67
0
)
Cap: 172163-1
Socket: 170361-1 or 170365-1
Case: 10320-52A0-008 (Manufactured by 3M.)
Connector: 10120-3000VE (Manufactured by 3M.)
**
Green/Yellow
White/Orange
Orange
White/Grey
Blue
White/Blue
Yellow
White/Yellow
Green
White/Green
Purple
White/Purple
Red
Black
P: twisted-pair shielded cables.
* Purchase caps, sockets, cases, and connectors separately. Refer to 3.
Connector Kits for details.
2) Details of the encoder cables are summarized in the table below.
These cables are not supplied as accessories with a Servopack or Servomotor.
Purchase in standard specified lengths as required.
5
