5.6Specifications and Dimensional Drawings of Peripheral Devices
323
Type L in mm (feet)
B9400064-1
3000
+100
0
(10
+0.33
0
)
B9400064-2
5000
+100
0
(16.7
+0.33
0
)
B9400064-3
10000
+500
0
(33.3
+1.67
0
)
B9400064-4
15000
+500
0
(50
+1.67
0
)
B9400064-5
20000
+500
0
(66.7
+1.67
0
)
Cap: 172161-1 (Manufactured by AMP.)
Socket: 170361-1 or 170365-1
(Manufactured by AMP.)
Case: 10320-52A0-008 (Manufactured by 3M.)
Connector: 10120-3000VE (Manufactured by 3M.)
Encoder End
Blue
White/Blue
Yellow
White/Yellow
Green
White/Green
Red
Black
Green/Yellow
Connector
Servopack End
P: twisted-pair shielded cables.
*
*
7
8
* Purchase caps, sockets, cases, and connectors separately. Refer to 3.
Connector Kits for details.
f) Cables for Absolute Encoder (Cable Only)
Cable AWG22 x 3C, AWG26 x 6P
5
