A.d00
Position Error Pulse
Overflow
Position error pulses exceeded parameter
(Pn520).
Gr.1 Available
LLH
A.d01
Position Error Pulse
Overflow Alarm at Servo
ON
Position error pulses accumulated too
much.
Gr.1 Available
A.d02
Position Error Pulse
Overflow Alarm by Speed
Limit at Servo ON
After a position error pulse has been input,
Pn529 limits the speed if the /S_ON signal
is turned ON. If Pn529 limits the speed in
such a state, this alarm occurs when refer-
ence pulses are input and the number of
position error pulses exceeds the value set
for parameter Pn520 (Excessive Position
Error Alarm Level).
Gr.2 Available
A.d10
Motor-load Position Error
Pulse Overflow *
Position error between motor and load is
excessive.
Gr.2 Available
A.Eb1
Safety Function Signal
Input Timing Error
The safety function signal input timing is
faulty.
Gr.1 N/A H L L
A.F10
Main Circuit Cable Open
Phase
With the main power supply ON, voltage
was low for more than 1 second in phase-R,
-S or -T.
Gr.2 Available H L H
CPF00
Digital Operator
Transmission Error 1
Digital operator (JUSP-OP05A) fails to
communicate with the SERVOPACK (e.g.,
CPU error).
− N/A
Undefined
CPF01
Digital Operator
Transmission Error 2
− N/A
A.− − Not an error Normal operation status −−HHH
∗ The alarm that may occur in a SERVOPACK with option module for fully-closed loop control.
(cont’d)
Alarm
Display
Alarm Name Meaning
Servo-
motor
Stop
Method
Alarm
Reset
Alarm Code Output
ALO1 ALO2 ALO3
