4.9 Displaying Help
Displaying Help
Press the help key (
?
) to display help.
The table of contents and index appear in the left frame, and text appears in the right frame.
Switching between Frames
To switch to the frame that you want to control, use the left and right arrow keys.
Moving Cursors and Scrolling
To scroll through the screen or to move the cursor in the table of contents or index, turn the jog shuttle.
Moving to the Link Destination
To move to a description that relates to blue text or to move from the table of contents or index to the
corresponding description, move the cursor to the appropriate blue text or item, and press SET.
Displaying Panel Key Descriptions
With help displayed, press a panel key to display an explanation of it.
Returning to the Previous Screen
To return to the previous screen, press RESET.
Hiding Help
Press the help key (
?
) to clear help.

YOKOGAWA DL850 ScopeCorder Specifications

General

Maximum Sampling Rate	100 MS/s
Power Supply	100 to 240 VAC, 50/60 Hz
Resolution	16-bit
Operating Temperature	5 to 40°C
Bandwidth	20 MHz
Input Types	Voltage, Temperature, Strain, Acceleration, Frequency, Logic, Current
Interfaces	Ethernet, USB, GP-IB
Trigger Modes	Edge, Window, Pattern
Number of Channels	Up to 128 (with multiple input modules)
Memory Capacity	Up to 2 G points (with /M4 option)
