2.1 Vertical and Horizontal Axes
Vertical Axis
This section explains how to configure the signal input settings and the amplitude-direction display
settings. The items that can be set vary depending on the installed modules. The channel menu that
corresponds to the key you pressed (CH1 to CH16) appears. You can set the various vertical axis
settings for each channel. Press ALL CH to display a screen in which you can configure the settings of
all channels while viewing the settings in a list.
DL850/DL850V Measurement Items
When the DL850/DL850V is equipped with the modules listed below, it can measure voltage,
temperature, strain, acceleration, frequency, logic, CAN bus signals, LIN bus signals, and so on.
Voltage
701250 (HS10M12), 701251 (HS1M16), 701255 (NONISO_10M12), 701267 (HV (with RMS)),
720210 (HS100M12), 701261 (UNIVERSAL), 701262 (UNIVERSAL (AAF)), 701265 (TEMP/HPV),
701275 (ACCL/VOLT)
Voltage (For the 16-CH Voltage Input Module)
720220 (16CH VOLT)
Temperature
701261 (UNIVERSAL), 701262 (UNIVERSAL (AAF)), 701265 (TEMP/HPV)
Temperature (For the 16-CH Temperature/Voltage Input Module)
720221 (16CH TEMP/VOLT)
Strain
701270 (STRAIN_NDIS), 701271 (STRAIN_DSUB)
Acceleration
701275 (ACCL/VOLT)
Frequency
701280 (FREQ)
Logic
720230 (LOGIC)
CAN Bus Signal Monitoring
720240(CAN MONITOR), 720241(CAN & LIN)
This module can only be used with the DL850V.
LIN Bus Signal Monitoring
720241(CAN & LIN)
This module can only be used with the DL850V.
Chapter 2 Main Features

YOKOGAWA DL850 ScopeCorder Specifications

General

Maximum Sampling Rate	100 MS/s
Power Supply	100 to 240 VAC, 50/60 Hz
Resolution	16-bit
Operating Temperature	5 to 40°C
Bandwidth	20 MHz
Input Types	Voltage, Temperature, Strain, Acceleration, Frequency, Logic, Current
Interfaces	Ethernet, USB, GP-IB
Trigger Modes	Edge, Window, Pattern
Number of Channels	Up to 128 (with multiple input modules)
Memory Capacity	Up to 2 G points (with /M4 option)
