iii
IM DL850-03EN
Checking the Contents of the Package
Unpack the box, and check the contents before operating the instrument. If the wrong items have been
delivered, if items are missing, or if there is a problem with the appearance of the items, contact your
nearest YOKOGAWA dealer.
DL850/DL850V
Check that the product that you received is what you ordered by referring to the model name and suffix
code given on the name plate on the left side panel.
Made in Japan
Made in Japan
MODEL Suffix Code Description
DL850/DL850V Main device, 8 slots, 250 Mpoint memory
Power cord
1
-D UL/CSA Standard power cord (Part No.: A1006WD)
[Maximum rated voltage: 125 V]
-F VDE Standard Power Cord (Part No.: A1009WD)
[Maximum rated voltage: 250 V]
-Q BS Standard Power Cord (Part No.: A1054WD)
[Maximum rated voltage: 250 V]
-R AS Standard Power Cord (Part No.: A1024WD)
[Maximum rated voltage: 250 V]
-H GB Standard Power Cord (Part No.: A1064WD)
[Maximum rated voltage: 250 V]
Language -HJ Japanese
-HE English
-HC Chinese
-HK Korean
-HG German
-HF French
-HL Italian
-HS Spanish
Options /B5 Built-in printer
2
/DC 12 VDC Power (10 to 18 VDC) (DL850V only)
3
/M1 Memory expansion to 1 Gpoint
4
/M2 Memory expansion to 2 Gpoint
4
/HD0 External HDD interface
5
/HD1 160 GB internal HDD
5
/C1 GP-IB interface
6
/C20 GP-IB interface + IRIG
6
/G2 User-defined computation
/G3 Real Time Math
/P4 Probe power supply, four outputs
1
Make sure that the attached power cord meets the designated standards of the country and area that you are
using it in.
2 Includes one roll of paper (B9988AE)
3 The /DC option can only be installed on the DL850V.
The /DC and /B5 options cannot be installed on the same
instrument.
4 The /M1 and /M2 options cannot be installed on the same instrument.
5 The /HD0 and /HD1 options cannot be installed on the same instrument.
6 The /C1 and /C20 options cannot be installed on the same instrument.
To Next Page
