YOKOGAWA DL850 ScopeCorder User Manual

6-12
IM DL850-03EN
6.10 Auxiliary I/O Section
External Trigger Input (TRIGGER IN)
Item Specifications
Connector type BNC
Input level TTL
Minimum pulse width 100 ns
Detected edge Rising or falling
Trigger delay time Within 100 ns + 1 sample
Trigger Output (TRIGGER OUT)
Item Specifications
Connector type BNC
Output level 5 V CMOS
Logic Low when a trigger occurs and high after acquisition is completed
Output delay Within 100 ns + 1 sample
Output hold time 100 ns or more
External Clock Input (EXT CLK IN)
Item Specifications
Connector type BNC
Input level TTL
Minimum pulse width 50 ns
Detected edge Rising
Sampling jitter Within 100 ns + 1 sample
Video Signal Output (VIDEO OUT)
Item Specifications
Connector type D-sub 15 pin receptacle
Output format Analog RGB
Output resolution XGA-compliant output, 1024 × 768 dots
Approx. 60 Hz Vsync (dot clock frequency: 66 MHz)
GO/NO-GO Determination I/O
Item Specifications
Connector type RJ-11 modular jack
Input level TTL or contact
Output level 5 V CMOS
External Start/Stop Input
Item Specifications
Connector type RJ-11 modular jack
Input level TTL or contact

YOKOGAWA DL850 ScopeCorder Specifications

General

Maximum Sampling Rate	100 MS/s
Power Supply	100 to 240 VAC, 50/60 Hz
Resolution	16-bit
Operating Temperature	5 to 40°C
Bandwidth	20 MHz
Input Types	Voltage, Temperature, Strain, Acceleration, Frequency, Logic, Current
Interfaces	Ethernet, USB, GP-IB
Trigger Modes	Edge, Window, Pattern
Number of Channels	Up to 128 (with multiple input modules)
Memory Capacity	Up to 2 G points (with /M4 option)
