App-24
IM DL850-03EN
Appendix 4 USB Keyboard Key Assignments
DL850/DL850V USB Keyboard
AQUIRE CTRL+A
MATH CTRL+B
Execute PRINT CTRL+C or PRINT SCREEN
DISPLAY CTRL+D
FILE CTRL+F
HELP CTRL+G
HISTORY CTRL+H
Execute SAVE CTRL+I
MANUALTRIG CTRL+J
KEY PROTECT CTRL+K
ALL CH CTRL+L
MEASURE CTRL+M
NUM LOCK CTRL+N
POSITION/DELAY CTRL+P
Execute CLEAR TRACE CTRL+Q
Execute RESET CTRL+R
SHIFT CTRL+S
MODE (TRIGGER) CTRL+T
CURSOR CTRL+U
SIMPLE/ENHANCED CTRL+W
ZOOM CTRL+Z
CH1 CTRL+1
CH2 CTRL+2
CH3 CTRL+3
CH4 CTRL+4
CH5 CTRL+5
CH6 CTRL+6
CH7 CTRL+7
CH8 CTRL+8
CH9 CTRL+9
CH10 CTRL+0
SET CTRL+ENTER
SETUP CTRL+\
UTILITY CTRL+/
CH11 CTRL+F1
CH12 CTRL+F2
CH13 CTRL+F3
CH14 CTRL+F4
CH15 CTRL+F5
CH16 CTRL+F6
Turn ZOOM POSITION to the right CTRL+INSERT
Turn VERTICAL POSITION to the right CTRL+HOME
Turn ZOOM POSITION to the left CTRL+DELETE
Turn VERTICAL POSITION to the left CTRL+END
START/STOP CTRL+* or F12
DUAL CAPTURE CTRL+SHIFT+A
FFT CTRL+SHIFT+B
PRINT MENU CTRL+SHIFT+C
X-Y CTRL+SHIFT+D
MENU CTRL+SHIFT+I
GO/NO-GO CTRL+SHIFT+M
ACTION CTRL+SHIFT+T
SEARCH CTRL+SHIFT+Z
CAL CTRL+SHIFT+\
EXP (CH key) E when NUM LOCK is illuminated on the DL850/DL850V
k (CH key) + ENTER (CH key) K when NUM LOCK is illuminated on the DL850/DL850V
m (CH key) + ENTER (CH key) M when NUM LOCK is illuminated on the DL850/DL850V
