YOKOGAWA DL850 ScopeCorder User Manual

App-19
IM DL850-03EN
Appendix
1
2
3
4
5
6
App
Index
Appendix 3 Default Values
Operation Key Soft Key Setting
CH1 to 16 (HS10M12 (701250))
V/div 50.0 V/div
Position 0.00 div
Label Channel number
Coupling DC
Probe 10:1
BandWidth Full
V Scale DIV
V Zoom ×1
Offset 0.0 V
Invert OFF
Linear Scale OFF
CH1 to 16 (HS1M16 (701251))
V/div 50.0 V/div
Position 0.00 div
Label Channel number
Coupling DC
Probe 10:1
BandWidth Full
V Scale DIV
V Zoom ×1
Offset 0.00 V
Invert OFF
Linear Scale OFF
CH1 to 16 (NONISO_10M12 (701255))
V/div 50.0 V/div
Position 0.00 div
Label Channel number
Coupling DC
Probe 10:1
BandWidth Full
V Scale DIV
V Zoom ×1
Offset 0.0 V
Invert OFF
Linear Scale OFF
CH1 to 16 (HV (with RMS) (701267))
V/div 5.000 V/div
Position 0.00 div
Label Channel number
Coupling DC
Probe 1:1
BandWidth Full
V Scale DIV
V Zoom ×1
Offset 0.000 V
Invert OFF
Linear Scale OFF
CH1 to 16 (UNIVERSAL (701261)/UNIVERSAL (AAF)
(701262))
V/div 5.000 V/div
Position 0.00 div
Label Channel number
Coupling DC
BandWidth Full
V Scale DIV
V Zoom ×1
Operation Key Soft Key Setting
CH1 to 16 (UNIVERSAL (701261)/UNIVERSAL (AAF)
(701262))
Offset 0.000 V
Invert OFF
Linear Scale OFF
CH1 to 16 (TEMP/HPV (701265))
V/div 5.000 V/div
Position 0.00 div
Label Channel number
Coupling DC
BandWidth Full
V Scale DIV
V Zoom ×1
Offset 0.000 V
Invert OFF
Linear Scale OFF
CH1 to 16 (STRAIN_NDIS (701270)/STRAIN_DSUB
(701271))
Value/div 4000.0 µSTR/div
Range ±20000 µSTR
Label Channel number
Excitation 2 V
Gauge Factor 2.00
BandWidth Full
Upper 20000 µSTR
Lower –20000 µSTR
Range Unit µSTR
Invert OFF
Linear Scale OFF
CH1 to 16 (ACCL/VOLT (701275))
V/div 50.0 V/div
Position 0.00 div
Label Channel number
Coupling DC
Probe 10:1
BandWidth Full
V Scale DIV
V Zoom ×1
Offset 0.00 V
Invert OFF
Linear Scale OFF
CH1 to 16 (FREQ (701280))
Value/div 1 kHz/div
Position 0.00 div
Label Channel number
FV Setup Frequency
Input Setup User
V Scale DIV
V Zoom ×1
Offset 0.000 Hz
Linear Scale OFF
CH1 to 16 (HS100M12 (720210))
V/div 50.0 V/div
Position 0.00 div
Label Channel number
Coupling DC
Probe 10:1
BandWidth Full

YOKOGAWA DL850 ScopeCorder Specifications

General

Maximum Sampling Rate	100 MS/s
Power Supply	100 to 240 VAC, 50/60 Hz
Resolution	16-bit
Operating Temperature	5 to 40°C
Bandwidth	20 MHz
Input Types	Voltage, Temperature, Strain, Acceleration, Frequency, Logic, Current
Interfaces	Ethernet, USB, GP-IB
Trigger Modes	Edge, Window, Pattern
Number of Channels	Up to 128 (with multiple input modules)
Memory Capacity	Up to 2 G points (with /M4 option)
