Optional Accessories (Sold Separately)
The optional accessories below are available for purchase separately. Check that all contents
are present and undamaged. For information about ordering accessories, contact your nearest
YOKOGAWA dealer.
Name Model Safety standard
1
Note
Isolated probe 700929 1000 Vrms CAT II 10:1 safety probe for the 701250, 701251, and 720210
701947 1000 Vrms CAT II 100:1 safety probe for the 701250, 701251, and 720210
Current probe 701933 300 Vrms 30 Arms, DC to 50 MHz. Used by connecting to a probe power
terminal (/P4 option) or a probe power supply (701934; sold
separately).
701930 300 Vrms CAT III 150 Arms, DC to 10 MHz. Used by connecting to a probe power
terminal (/P4 option) or a probe power supply (701934; sold
separately).
701931 300 Vrms CAT III 500 Arms, DC to 2 MHz. Used by connecting to a probe power
terminal (/P4 option) or a probe power supply (701934; sold
separately).
10:1 passive probe 701940 — For non-isolated input on the 701255: 600 V or less
For isolated input other than above: 42 V or less
Differential probe 700924 1000 Vrms CAT III
2
Switchable between 1000:1 and 100:1
Measurable voltage: 1400 Vpeak (1000 Vrms)
1:1 BNC safety adapter lead 701901 1000 Vrms CAT II For use with the 701250, 701251, and 720210. Used with the
following items (which are sold separately): the 701954, 701959,
758922, 758929, or 758921.
Measurement lead 758933 1000 Vrms CAT III 1 m in length; for use with the 701267. Used with the following items
(which are sold separately): the 701954, 701959, 758922, 758929,
or 758921.
Alligator clip (dolphin type) 701954 1000 Vrms CAT III Two pieces in one set (red/black)
Safety mini-clip (hook type) 701959 1000 Vrms CAT II Two pieces in one set (red/black)
Alligator clip adapter 758922 300 Vrms CAT II Two pieces in one set
Alligator clip adapter 758929 1000 Vrms CAT II Two pieces in one set
Fork terminal adapter 758921 1000 Vrms CAT II Two pieces in one set (red/black). For 4 mm screws.
Cable
3
366926 — For measuring low voltage of less than or equal to 42 V
Banana–alligator clip cable 366961 — For measuring low voltage of less than or equal to 42 V for the
701261, 701262, or 701265
High-speed logic probe 700986 — 42 V or less, 8 bits, non-isolated, response speed of 1 μs
Isolated logic probe 700987 250 Vrms CAT II 8 bits, each channel isolated, response speed of 20 ms (for AC)
1 m logic probe 702911 — 8 bits, non-isolated
3 m logic probe 702912 — 8 bits, non-isolated
Isolated logic measurement
lead
758917 1000 Vrms CAT II Two pieces in one set. Used with the 758922 or 758929 adapter.
The adapters are sold separately.
External I/O cable 720911 — For external I/O
1 m safety BNC cable 701902 1000 Vrms CAT II —
2 m safety BNC cable 701903 1000 Vrms CAT II —
Safety BNC-to-banana
adapter
758924 500 Vrms CAT II For the 701250, 701251, 701255, and 720210
Probe power supply 701934 — High current output power supply for external probes (four outputs)
Shunt resistor 438920 — 250 Ω ± 0.1%
438921 — 100 Ω ± 0.1%
438922 — 10 Ω ± 0.1%
16-CH scanner box Accessory: Protection cover 1, Protection cover screw 1, Attaching plate 1, Binding screw 2
701953-L1 — For the 720221; cable length: 1 m
701953-L3 — For the 720221; cable length: 3 m
Cable 705926 — 1 m in length; for connecting the 720221 and 701953
Cable 705927 — 3 m in length; for connecting the 720221 and 701953
Bridgehead 701955 — NDIS, bridge resistance: 120 Ω
701956 — NDIS, bridge resistance: 350 Ω
701957 — DSUB, bridge resistance: 120 Ω, shunt-cal support
701958 — DSUB, bridge resistance: 350 Ω, shunt-cal support
Soft carrying case 701963 Has three pockets
DC power cord
(Cigarette lighter plug type)
701970 — For the DC power supply model (/DC)
DC power cord
(Alligator clip type)
701971 — For the DC power supply model (/DC)
Checking the Contents of the Package
