Appendix 1 Relationship between the Time Axis
Setting, Record Length, and Sample Rate
When the High-Speed 100 MS/s, 12-Bit Isolation Module Is Installed
When the Record Length Is 1 kpoint, 2.5 kpoint, 5 kpoint, 10 kpoint, or 25 kpoint
Record
1 kpoint 2.5 kpoint 5 kpoint 10 kpoint 25 kpoint
Time/div Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points
)
100 ns 100 M 100 100 M 100 100 M 100 100 M 100 100 M 100
200 ns 100 M 200 100 M 200 100 M 200 100 M 200 100 M 200
500 ns 100 M 500 100 M 500 100 M 500 100 M 500 100 M 500
1 μs 100 M 1 k 100 M 1 k 100 M 1 k 100 M 1 k 100 M 1 k
2 μs 50 M 1 k 100 M 2 k 100 M 2 k 100 M 2 k 100 M 2 k
5 μs 20 M 1 k 50 M 2.5 k 100 M 5 k 100 M 5 k 100 M 5 k
10 μs 10 M 1 k 20 M 2 k 50 M 5 k 100 M 10 k 100 M 10 k
20 μs 5 M 1 k 10 M 2 k 20 M 4 k 50 M 10 k 100 M 20 k
50 μs 2 M 1 k 5 M 2.5 k 10 M 5 k 20 M 10 k 50 M 25 k
100 μs 1 M 1 k 2 M 2 k 5 M 5 k 10 M 10 k 20 M 20 k
200 μs 500 k 1 k 1 M 2 k 2 M 4 k 5 M 10 k 10 M 20 k
500 μs 200 k 1 k 500 k 2.5 k 1 M 5 k 2 M 10 k 5 M 25 k
1 ms 100 k 1 k 200 k 2 k 500 k 5 k 1 M 10 k 2 M 20 k
2 ms 50 k 1 k 100 k 2 k 200 k 4 k 500 k 10 k 1 M 20 k
5 ms 20 k 1 k 50 k 2.5 k 100 k 5 k 200 k 10 k 500 k 25 k
10 ms 10 k 1 k 20 k 2 k 50 k 5 k 100 k 10 k 200 k 20 k
20 ms 5 k 1 k 10 k 2 k 20 k 4 k 50 k 10 k 100 k 20 k
50 ms 2 k 1 k 5 k 2.5 k 10 k 5 k 20 k 10 k 50 k 25 k
100 ms 1 k 1 k 2 k 2 k 5 k 5 k 10 k 10 k 20 k 20 k
200 ms 500 1 k 1 k 2 k 2 k 4 k 5 k 10 k 10 k 20 k
500 ms 200 1 k 500 2.5 k 1 k 5 k 2 k 10 k 5 k 25 k
1 s 100 1 k 200 2 k 500 5 k 1 k 10 k 2 k 20 k
2 s 50 1 k 100 2 k 200 4 k 500 10 k 1 k 20 k
3 s 20 600 50 1.5 k 100 3 k 200 6 k 500 15 k
4 s 20 800 50 2 k 100 4 k 200 8 k 500 20 k
5 s 20 1 k 50 2.5 k 100 5 k 200 10 k 500 25 k
6 s 10 600 20 1.2 k 50 3 k 100 6 k 200 12 k
8 s 10 800 20 1.6 k 50 4 k 100 8 k 200 16 k
10 s 10 1 k 20 2 k 50 5 k 100 10 k 200 20 k
20 s 5 1 k 10 2 k 20 4 k 50 10 k 100 20 k
30 s 5 1.5 k 10 3 k 20 6 k 50 15 k
1 min 5 3 k 10 6 k 20 12 k
2 min 5 6 k 20 24 k
3 min 5 9 k 10 18 k
4 min 10 24 k
5 min 5 15 k
6 min 5 18 k
7 min 5 21 k
When the time axis setting is 100 ms or greater (the settings surrounded by bold lines) and the trigger mode is Auto or Auto Level,
waveforms are displayed in roll mode.
