6.7 Built-in Printer
Item Specifications
Print system Thermal line dot system
Sheet width 112 mm
Effective print width 104 mm (832 dots)
Dot density 8 dot/mm
Feeding direction resolution 8 dot/mm
Used for Producing a hard copy of the screen
6.8 Storage
SD Memory Card
Item Specifications
Number of slots 1
Maximum capacity 16 GB
Supported cards SD and SDHC compliant memory cards
Internal HDD (/HD1 option)
Item Specifications
Number of drives 1
Size 2.5 in.
HDD capacity used 160 GB, FAT32
USB Ports for Peripherals
Item Specifications
Compatible USB storage
devices
Mass storage devices that are compliant with USB Mass Storage Class Ver. 1.1
External HDD Interface (/HD0 option)
Item Specifications
Connection interface eSATA
Number of drives 1
Usable HDD capacity 1.5 TB, FAT32
6.9 USB for Peripherals
Item Specifications
Connector type USB type A (receptacle)
Electrical and mechanical
specifications
USB Rev. 2.0 compliant
Supported transfer mode HS (High Speed; 480 Mbps), FS (Full Speed; 12 Mbps), LS (Low Speed; 1.5 Mbps)
Compatible devices Mass storage devices that are compliant with USB Mass Storage Class Ver. 1.1
104 or 109 keyboards that are compliant with USB HID Class Version 1.1
Mouse devices that are compliant with USB HID Class Version 1.1
Number of ports 2
Power supply 5 V, 500 mA (for each port)

YOKOGAWA DL850 ScopeCorder Specifications

General

Maximum Sampling Rate	100 MS/s
Power Supply	100 to 240 VAC, 50/60 Hz
Resolution	16-bit
Operating Temperature	5 to 40°C
Bandwidth	20 MHz
Input Types	Voltage, Temperature, Strain, Acceleration, Frequency, Logic, Current
Interfaces	Ethernet, USB, GP-IB
Trigger Modes	Edge, Window, Pattern
Number of Channels	Up to 128 (with multiple input modules)
Memory Capacity	Up to 2 G points (with /M4 option)
