Operation Key Soft Key Setting
V Scale DIV
V Zoom ×1
Offset 0.0 V
Invert OFF
Linear Scale OFF
CH1 to 16 (16CH VOLT (720220))
V/div 2.000 V/div
Position 0.00 div
Label Channel number
Coupling DC
BandWidth Full
V Scale DIV
V Zoom ×1
Offset 0 mV
Invert OFF
Linear Scale OFF
CH1 to 16 (16CH VOLT (720221))
V/div 2.000 V/div
Position 0.00 div
Data Update Period 100 ms
Label Channel number
Coupling DC
V Scale DIV
V Zoom ×1
Offset 0.0 mV
Invert OFF
Linear Scale OFF
CH1 to 16 (LOGIC (720230))
Position 0.00 div
Label Channel number
Bit Mapping Auto
CH13 to 16 (CAN MONITOR (720240))
All SubChannels Setup
Input OFF
Label Channel number
Message Format STD
ID (Hex) 000
Byte Count Auto
Start Bit 0
Bit Count 8
Byte Order Big
Value Type Unsigned
Factor 1.0000
Offset 0.0000
Port Setup
Bit Rate 500 Kbps
Sample Point 85%
Sync Jump Width 2
Bit Sample Num 1
Listen Only OFF
Terminator OFF
Scale Auto
One Shot Out
Message Format STD
ID (Hex) 000
Frame Data
DLC 0
Data (Hex) 00 00 00 00
00 00 00 00
Operation Key Soft Key Setting
CH13 to 16 (CAN & LIN (720241))
The values for CAN are the same as the
values for the 720240.
All SubChannels Setup
Input OFF
Label Channel number
ID (Hex) 000
Start Bit 0
Bit Count 8
Byte Order Little
Value Type Unsigned
Factor 1.0000
Offset 0.0000
Port Setup
Bit Rate 19200 bps
Frame Setup
Data Length 1
Check Sum Classic
Scale Auto
START/STOP
STOP
TIME/DIV
1 ms/div
ACQUIRE
Record Length 10 k
Acquisition Mode Normal
Trigger Mode Auto
Acquisition Count Infinite
HD Recording OFF
Time Base Int
DUAL CAPTURE
Mode OFF
Capture Setup
Time/div 100 µs/div
Capture Length 10 k
Capture Mode Auto
Select Number Current
Mag 100 µs/div
Position 0.0 div
Window ON
Main Ratio 50%
Window Layout Side
Format Main
Event Display OFF
