YOKOGAWA DL850 ScopeCorder User Manual

xvi
IM DL850-03EN
3.3-3.16, 3-18, 5.1-5.6 , 6.13
に
を添付
Chapter 5 External Signal I/O
5.1 External Trigger Input (TRIGGER IN) ............................................................................... 5-1
5.2 Trigger Output (TRIGGER OUT) ...................................................................................... 5-2
5.3 External Clock Input (EXT CLK IN) .................................................................................. 5-3
5.4 Video Signal Output (VIDEO OUT (XGA)) ....................................................................... 5-4
5.5 GO/NO-GO Determination I/O and External Start/Stop Input (EXT I/O) .......................... 5-5
5.6 IRIG Signal Input (IRIG option) ........................................................................................ 5-8
Chapter 6 Specifications
6.1 Signal Input Section ......................................................................................................... 6-1
6.2 Triggering Section ............................................................................................................ 6-1
6.3 T
ime Axis .......................................................................................................................... 6-3
6.4 Display .......................................................................................................
....................... 6-3
6.5 Features
........................................................................................................................... 6-4
6.6 FFT ......................................................................................................
........................... 6-10
6.7 Built-in Printer .......................................................................................................
...........6-11
6.8 Storage
............................................................................................................................6-11
6.9 USB for Peripherals .......................................................................................................
..6-11
6.10 Auxiliary I/O Section
....................................................................................................... 6-12
6.11
Computer Interface ......................................................................................................... 6-14
6.12 General Specifications ................................................................................................... 6-15
6.13 Module Specifications .................................................................................................... 6-19
6.14 Logic Probe Specifications ............................................................................................. 6-51
6.15 16-CH Scanner Box Specifications ................................................................................ 6-52
6.16 External Dimensions ...................................................................................................... 6-53
Appendix
Appendix 1 Relationship between the Time Axis Setting, Record Length, and Sample Rate .....App-1
Appendix 2 Relationship between the Record Length and the Acquisition Mode ............... App-17
Appendix 3 Default V
alues .................................................................................................. App-19
Appendix 4 USB Keyboard Key
Assignments .....................................................................App-24
Appendix 5 Block Diagrams ................................................................................................App-26
Appendix 6 High-Voltage 100 kS/s, 16-Bit Isolation Module (with RMS) (701260) Specifications .. App-28
Contents

YOKOGAWA DL850 ScopeCorder Specifications

General

Maximum Sampling Rate	100 MS/s
Power Supply	100 to 240 VAC, 50/60 Hz
Resolution	16-bit
Operating Temperature	5 to 40°C
Bandwidth	20 MHz
Input Types	Voltage, Temperature, Strain, Acceleration, Frequency, Logic, Current
Interfaces	Ethernet, USB, GP-IB
Trigger Modes	Edge, Window, Pattern
Number of Channels	Up to 128 (with multiple input modules)
Memory Capacity	Up to 2 G points (with /M4 option)
