Signals That Auto Setup Can Be Applied To
Frequency: Approx. 50 Hz or higher
Absolute input voltage: Signals whose maximum value is at least approx. 20 mV (at 1:1 setting)
Type: Simple, repeating signals
Note
The auto setup feature may not work properly for signals that include a DC component or high-frequency
components.
Settings after the Execution of Auto Setup
Waveform Acquisition and Display Settings
T/div The waveform with the shortest period out of the
waveforms affected by auto setup is used to set T/div.
T/div is set to the value at which 1.6 to 4 periods of the
waveform can be displayed.
START/STOP START
Acquisition mode Normal
Acquisition count Infinite
Record length 10 k
Time base Int.
Real-time HD recording Off
Dual capturing Off
Accumulation Off
Vertical axis settings
V/Div The value that causes the absolute values of the input
waveform to be between 1.6 and 4.5 div
Offset voltage 0 V
Coupling DC
Bandwidth limit FULL
Display on/off Channels whose absolute input voltage values reach or
exceed 20 mV (1:1) are displayed (except for Scan).
The displays of modules that are not affected by auto
setup do not change.
DIV/Scale DIV
Position 0.00 div
V Zoom ×1
Trigger Settings
Trigger mode Auto
Trigger type SIMPLE
Trigger source The channel with the longest period out of the channels
whose amplitude is 1 div or greater
Trigger level/slope The level between the maximum and minimum values/
rising
Hysteresis Low
Hold-off 0.0 nsec
Trigger position 50%
Trigger delay 0.0 μsec
Computation Settings
Math Off
The values of settings not listed here do not change.
4.5 Performing Auto Setup
