Computation on All History Waveforms
If you press the Math on History Exec soft key while the waveform acquisition is stopped,
the user-defined computation is performed on all history waveforms of the source
channel.
Note
• User-defined computation cannot be performed on all history waveforms while waveforms
are being acquired.
• The computation-in-progress icon appears at the lower left of the screen, and a progress
bar is displayed in the center of the screen while the user-defined computation on all history
waveforms is in progress. All operations other than the Abort soft key are disabled.
• If you set the trigger mode to N Single and start the waveform acquisition, user-defined
computation is performed only on the latest waveform after the acquisition is stopped. To
perform user-defined computation on all history waveforms, carry out the procedure given in
“Executing the Computation on All History Waveforms.”
• If you change a setting that affects the user-defined computation result, recomputation is
performed only on the selected history waveform.
• The Average display of HISTORY or PARAM of History Statistics appears only if all history
waveforms exist. If the Average display of History or PARAM of History Statistics is not
performed, carry out the procedure given in “Executing the Computation on All History
Waveforms.”
9.10 User-Defined Computation (Optional)
