10.1 Measuring Using Cursors

Procedure

CURSOR

PARAM

TELECOM

TEST

WINDOW 1

WINDOW 2

FORM

ACCUM

CLEAR

ZOOM 1

ZOOM 2

DISP

MAG

INTENSITY

MEASURE

ANALYSIS

DISPLAY ZOOM

ACCUM

Press CURSOR.

Cursors appear.

Selecting the Cursor Type

Press the Type soft key.

Press the appropriate soft key from Vertical to Serial to select the cursor type.

Proceed to the steps on the pages indicated below according to the selected cursor.

• Vertical: Step 4 on page 10-2

• Horizontal: Step 4 on page 10-3

•

H&V (horizontal & vertical): Step 4 on page 10-5

• VT

: Step 4 on page 10-7

• Marker: Step 4 on page 10-9

•

Serial: Step 4 on page 10-1
