Explanation
Source Waveform
Select the source waveform from CH1 to CH4 or from M1 to M4.
Measurements cannot be made on a snapshot waveform or an accumulated waveform
that is not the most recent waveform.
Cursor Types and Measurement Items
• Vertical (V) Cursors
Measures the X-axis values at the cursor positions.
T1 T1 cursor X-axis value
T2 T2 cursor X-axis value
Δ
T
Difference between the X-axis values of the T1 and T2 cursors
1/
Δ
T
Reciprocal of the difference between the X-axis values of the T1 and T2 cursors
• Horizontal (H) Cursors
Measures the Y-axis values at the cursor positions.
V1 V1 cursor Y-axis value
V2 V2 cursor Y-axis value
Δ
V
Difference between the Y-axis values of the V1 and V2 cursors.
• Horizontal&Vertical (H&V) Cursors
Measures the X-axis value and the Y-axis value at the cursor p
ositions.
X-axis
T1 T1 cursor X-axis value
T2 T2 cursor X-axis value
Δ
T
Difference between the X-axis values of the T1 and T2 cursors
1/
Δ
T
Reciprocal of the difference between the X-axis values of the T1 and T2 cursors
Y-axis
V1 V1 cursor Y-axis value
V2 V2 cursor Y-axis value
Δ
V
Difference between the Y-axis values of the V1 and V2 cursors.
• Vertical Time (VT) Cursor
Measures the time from the trigger position to the VT cursor and the selected
waveform data value at the VT cursor
.
CH1 to CH4
V(CH1) CH1 Y-axis value
V(CH2) CH2 Y-axis value
V(CH3) CH3 Y-axis value
V(CH4) CH4 Y-axis value
V(M1) M1 Y-axis value
V(M2) M2 Y-axis value
V(M3) M3 Y-axis value
V(M4) M4 Y-axis value
T X-axis value
10.1 Measuring Using Cursors
