13-20
IM 701310-01E
Explanation
Storage Medium and Directory
Storage media in which saving and loading are possible are displayed on the File List
window.
Display Examples of Storage Media
Same as the explanation given in “Display Examples of Storag
e Media” of section
13.4.
File Name and Comments
Same as the explanations given in “File Name” and “Comment” in section 13.4.
Specifying the Files to Be Displayed in the File List Dialog Box
See the explanation “Specifying the Files to Be Displayed in the File List Dialog Box” in
section 13.4.
Note
• An error occurs if a key other than the Abort key is pressed while saving or loading a file.
• When measurement data is loaded, the accumulate setting is always OFF.
• If you change the extension of the saved data (using a PC, for example), the file can no
longer be loaded.
•
A total of 2500 directories and files can be displayed in the file list. If there are more than
2500 directories and files in a single directory, a total of 2500 files and directories will be
displayed, but it is not possible to specify which directories and files are displayed.
13.6 Saving and Loading Accumulated and Snapshot Waveforms
To Next Page
