Accessories
131
Two Charger Setup
1. Plug the 2-way DC Cable plugs into the power port on the back of each charger.
2. Plug the 2-way DC Cable connector into the power output of the power supply (PWR-BGA12V108W0WW).
3. Plug the AC line cord into the power supply.
1 Power supply
2 AC line cord
3 DC line cord
2
1
3
