Accessories
147
Trigger Handle
NOTE: The Rugged Boot is required to install the Trigger Handle onto the device. Trigger Handle (p/n
TRG-TC51-SNP1-01) does not contain the Rugged Boot and must be purchased separately. Trigger Handle
Kit (p/n TRG-TC51-TRG1-01) contains the Rugged Boot.
The Trigger Handle adds a gun-style handle with a scanning trigger to the device. It increases comfort when
using the device in scan-intensive applications for extended periods of time.
The Trigger Handle is available for the TC52 standard configuration. It is also available for the TC52-HC
configuration.
Figure 68 Trigger Handle
Installing the Rugged Boot
NOTE: If a Hand Strap is attached to the Rugged Boot, remove prior to installing onto device.
To install the Rugged Boot:
1 Flange
2 Lanyard mount
3 Release latch
4 Trigger
4 3
2
1
MN-003834-01ENa_tc52-android-10-ug-en.book Page 147
