Zebra TC52 Series User Manual

Data Capture
74
Scanning with the DS3678 Bluetooth Scanner
To scan with the DS3678:
1. Pair the scanner with the device. For more information, see Pairing Bluetooth Scanners.
2. Ensure that an app is open on the device and a text field is in focus (text cursor in text field).
3. Point the scanner at a barcode.
Figure 27 Barcode Scanning (DS3678 shown)
4. Press and hold the trigger.
Ensure the barcode is within the area formed by the aiming pattern. The aiming dot increases visibility in
bright lighting conditions.
Figure 28 DS3678 Aiming Pattern
Figure 29 DS3678 Pick List Mode with Multiple Barcodes in Aiming Pattern
5. The captured data appears in the text field.
Scanning with LI3678 Linear Imager
To scan with the LI3678:
MN-003834-01ENa_tc52-android-10-ug-en.book Page 74

Zebra TC52 Series Specifications

General

Processor	Qualcomm Snapdragon 660 octa-core, 2.2 GHz
Memory	4 GB RAM/32 GB Flash or 4 GB RAM/64 GB Flash
Front Camera	5 MP
Operating Temp	-4°F to 122°F/-20°C to 50°C
Operating System	Android
Touch Panel	Capacitive touch panel; multi-touch
Rear Camera	13 MP with autofocus and flash
Battery	Li-Ion 4150 mAh; Hot-swappable
Connectivity	Wi-Fi 802.11 a/b/g/n/ac
Drop Specification	Multiple 6 ft./1.8 m drops to concrete over operating temperature range
Tumble Specification	1000 tumbles at 0.5 m (1.6 ft)
Sealing	IP65
Expansion Slot	MicroSD
Scanner	SE4710 imager (1D and 2D barcode scanning)
Durability	Corning Gorilla Glass
Weight	8.8 oz./249 g
