Zebra TC52 Series User Manual

Data Capture
71
Figure 20 RS507/RS507X Pick List Mode with Multiple Barcodes in Aiming Pattern
5. The captured data appears in the text field.
Scanning with RS6000 Bluetooth Ring Scanner
To read a barcode, a scan-enabled app is required. Devices that contain the Zebra DataWedge app allows you
to enable the scanner to decode barcode data and display the barcode content.
To scan with the RS6000:
1. Pair the RS6000 with the device. See Pairing the Bluetooth Ring Scanner on page 76
for more information.
2. Ensure that an app is open on the device and a text field is in focus (text cursor in text field).
3. Point the RS6000 at a barcode.
Figure 21 Barcode Scanning with RS6000
4. Press and hold the trigger.
The red laser aiming pattern turns on to assist in aiming. Ensure the barcode is within the area formed by
the cross-hairs in the aiming pattern. The aiming dot increases visibility in bright lighting conditions.
The RS6000 LEDs light green and a beep sounds to indicate the barcode was decoded successfully. When
the RS6000 is in Pick List mode, the RS6000 does not decode the barcode until the center of the crosshair
touches the barcode.
MN-003834-01ENa_tc52-android-10-ug-en.book Page 71

Zebra TC52 Series Specifications

General

Processor	Qualcomm Snapdragon 660 octa-core, 2.2 GHz
Memory	4 GB RAM/32 GB Flash or 4 GB RAM/64 GB Flash
Front Camera	5 MP
Operating Temp	-4°F to 122°F/-20°C to 50°C
Operating System	Android
Touch Panel	Capacitive touch panel; multi-touch
Rear Camera	13 MP with autofocus and flash
Battery	Li-Ion 4150 mAh; Hot-swappable
Connectivity	Wi-Fi 802.11 a/b/g/n/ac
Drop Specification	Multiple 6 ft./1.8 m drops to concrete over operating temperature range
Tumble Specification	1000 tumbles at 0.5 m (1.6 ft)
Sealing	IP65
Expansion Slot	MicroSD
Scanner	SE4710 imager (1D and 2D barcode scanning)
Durability	Corning Gorilla Glass
Weight	8.8 oz./249 g
