Accessories
160
Figure 71 Install Rack System Screws
3. Align the mounting bracket’s top mounting key holes with the screws.
4. Place the brackets on the screws.
Figure 72 Secure Bracket to Rack (Horizontal Position Shown)
Rack Screws
14 “
