7 Troubleshooting | 7.1 Chamber ZEISS
Procedure
1. From the Menu Bar, select Stage > Stage Initialise.
à The Initialise Stage window is displayed.
2. Confirm via Yes.
à The stage initialization process takes a few minutes.
à INFO: If initialization of the stage does not solve the stage problem, contact your local
ZEISS service representative.
7.1.2 Defining the Post Initialization Position of the Stage
You can configure the position to which the stage drives after the initialization procedure. Other-
wise, the stage drives to the center position.
CAUTION
Moving the specimen stage
Fingers can be trapped by the moving specimen stage.
4 Always close the chamber door before moving the specimen stage.
4 To remove parts fallen into or near to the stage use a tool (e.g. tweezers) instead of your
fingers.
Prerequisite
ü
Requires the Supervisor privilege.
Procedure
1. From the Windows start menu, select SmartSEM > SmartSEM Administrator.
à The SmartSEM Administrator Log on window is displayed.
2. Enter user name and password.
3. To confirm, click OK.
à The SmartSEM Administrator window is displayed showing the user list.
4. Click Column/Stage.
5. In the Stage Post Initialisation Position input fields, enter the desired position.
Alternatively, use the dual joystick to navigate to the desired position and click Set to cur-
rent position.
6. To activate the function, activate the Post Init. Posn Valid checkbox.
7.1.3 Changing the Joystick TV Angle
In TV mode (chamberscope), the dual joystick and stage may appear to move in opposite direc-
tions. This is because the selected CCD camera is installed at a certain angle relative to the stage.
Thus, the camera shows a side-inverted view. To remedy this, you need to change the joystick TV
angle setting in the software.
Info
If you are working with two CCD cameras: The joystick TV angle can only be set for one CCD
camera. When selecting the other CCD camera, you have to change the setting.
CAUTION
Moving the specimen stage
Fingers can be trapped by the moving specimen stage.
4 Always close the chamber door before moving the specimen stage.
4 To remove parts fallen into or near to the stage use a tool (e.g. tweezers) instead of your
fingers.
116 Instruction Manual ZEISS EVO | en-US | Rev. 10 | 354706-0780-006
