Zeiss EVO - Performance Data and Specifications | EVO 15

ZEISS 9 Technical Data and Conformity | 9.4 Performance Data and Specifications | EVO 15
9.4 Performance Data and Specifications | EVO 15
The Microscope System must only be operated in closed rooms. It is recommended to install the
Microscope System in a dark room where artificial illumination, sunlight or other light sources
cannot interfere with image acquisition. The Microscope System should not be installed near win-
dows with direct sunlight or radiators. Compliance with the installation requirements of the Mi-
croscope System and the availability of the requested supplies is the responsibility of the customer
and has to be provided at the time of installation. Due to continuous development, we reserve the
right to change specifications without notice.
The Microscope System must be plugged into a properly installed power socket with protective
earth contact using the supplied mains cable. The protective earth connection must not be im-
paired by the use of extension cables.
Info
Your ZEISS Sales & Service Partner will provide you with the detailed installation requirements.
Weight and Sizes
Main Components Length
(mm)
Width (mm) Height
(mm)
Weight (kg)
Plinth + column 807 1031 1780 650
Overall 1930 1781 1780 720
Air Conditioning
and Quality
Parameter Value
Temperature range for operation with indi-
cated performance (24 h per day, regardless
of whether the microscope is in operation or
switched off)
20–30°C
It is recommended that for operator comfort
the room temperature is maintained between
22°C and 24°C.
Recommended best temperature stability ± 0.5°C/h
Long-term recommended stability not more than ±2°C/24h
Relative humidity < 65%
Altitude ≤2000m above sea level to guarantee an
undisturbed operation
Pollution degree 2
Mains Connection
Parameter Value
Nominal AC voltage 120V
AC
(single phase) or 230V
AC
(single
phase)
The provided electrical connection must be in
accordance with the applicable electrical
codes for the country of installation. In order
to avoid disturbance from other installed ma-
chines, ZEISS recommends using a separate
power connection to the main distribution
panel.
Nominal frequency 50–60Hz
Main Power Plug The microscope is delivered with a power
cord 3m long equipped with a CEE plug 1/N/
PE according to IEC60309 depending on the
customers site supply: either for 120V
AC
a
Instruction Manual ZEISS EVO | en-US | Rev. 10 | 354706-0780-006 159
