9 Technical Data and Conformity | 9.5 Performance Data and Specifications | EVO 25 ZEISS
Parameter Description
HDBSD detector (optional):
BSE imaging at low kV of metals, polymers, minerals, etc. both in HV
and VP modes.
YAG BSD detector (optional):
Robust, fully retractable, YAG-crystal-based BSE scintillator detector
with rise time ~200ns. Easy to use with no amplifier gain adjustment
required.
STEM detector (optional):
Scanning Transmission Electron Microscopy (STEM) detector, with pre-
aligned specimen holder and Bright-field (BF) STEM detector
CL detector (optional):
Cathodoluminiscence (CL) chamber detector (option for non-VP con-
figurations, included in VP option)
SCD (optional)
Specimen current detector
For more details refer to the document Product Specification.
9.5 Performance Data and Specifications | EVO 25
The Microscope System must only be operated in closed rooms. It is recommended to install the
Microscope System in a dark room where artificial illumination, sunlight or other light sources
cannot interfere with image acquisition. The Microscope System should not be installed near win-
dows with direct sunlight or radiators. Compliance with the installation requirements of the Mi-
croscope System and the availability of the requested supplies is the responsibility of the customer
and has to be provided at the time of installation. Due to continuous development, we reserve the
right to change specifications without notice.
The Microscope System must be plugged into a properly installed power socket with protective
earth contact using the supplied mains cable. The protective earth connection must not be im-
paired by the use of extension cables.
Info
Your ZEISS Sales & Service Partner will provide you with the detailed installation requirements.
Weight and Sizes
Main Components Length
(mm)
Width (mm) Height
(mm)
Weight (kg)
Plinth + column 807 1031 1780 650
Overall 1930 1781 1780 720
Air Conditioning
and Quality
Parameter Value
Temperature range for operation with indi-
cated performance (24 h per day, regardless
of whether the microscope is in operation or
switched off)
20–30°C
It is recommended that for operator comfort
the room temperature is maintained between
22°C and 24°C.
Recommended best temperature stability ± 0.5°C/h
Long-term recommended stability not more than ±2°C/24h
