5 Diagnostics
5-16 NetPath 100 User’s Manual - Installation Guide 980-001-0210G
June
1999
Octet Mode
The Octet Mode screen display is shown in Figure 5-10.
Fi
g
ure 5-10 PVC Statistics Summar
y
Screen (Octet Mode)
Octet Mode replaces some columns with the following additional statistics:
RxOcts and TxOcts - Count of octets within packets.
RxKbps and TxKbps - Data rate calculated from the total count of octets
counted for the particular PVC.
**************************** PVC Statistics Summary ****************************
Name: F243802 Mode[M=P,O,TC,RC,TL,RL,FD,orND]:Oct
(P=Pkt,O=Oct,TC=TxCir,RC=RxCir,TL=TxLoss,RL=RxLoss,FD=FullDlay,orND=NetwDlay)
First DLCI [P=#]: 16 Current Interval Count: 455 of 900 secs
DLCI RxPkts TxPkts RxOcts TxOcts RxKbps TxKbps
25 0 0 0 0 0 0
33 0 0 0 0 0 0
234 0 0 0 0 0 0
341 0 0 0 0 0 0
464 0 0 0 0 0 0
531 0 0 0 0 0 0
793 0 0 0 0 0 0
795 0 0 0 0 0 0
942 0 0 0 0 0 0
970 0 0 0 0 0 0
Etc 0 0 0 0 0 0
Sum 0 0 0 0 0 0
-- 15 Min Interval History: 96 Valid -- Past Summary for DLCI [D=#orSum]: Sum --
RxPkts TxPkts RxOcts TxOcts RxKbps TxKbps
10 Second: 0 21 0 567 0 0
History: 0 24965 0 674055 0 1
ResetStats[RS] ViewHistory[VH current_time(optional)]
Help[?] Close[X] NextPage[+] AutoUpdate[AU]
>
