980-001-0210G NetPath 100 User’s Manual - Installation Guide 3-1
June
1999
3 Installation
This section contains information to complete the physical installation of a
NetPath 100 which includes: mounting the unit, power connection, and input/output
connections.
Mounting
NetPath 100 comes equipped with rubber feet for table or shelf-top placement. Option-
al adapter brackets are available for wall mounting and standard 19" or 24" rack
mounting. Sufficient space for cooling and access to the front panel indicators for trou-
bleshooting are required in all installations.
CAUTION
Failure to provide adequate coolin
space may overheat
the unit and void the warranty.
1. Before unpacking, ensure that the factory carton does not show any signs of
damage. If it does, contact the freight carrier immediately.
2. Unpack the NetPath 100 and power cord from the factory carton(s). Check all the
components for signs of damage. If they appear damaged, contact your equipment
provider before proceeding.
3. Mount the NetPath 100 in its operating location. Table-top or shelf-top location is
assumed in this manual.
CAUTION
Select a location where the unit will not be disturbed
once it is operational. Do not place the NetPath 100 on
top of any heat-producin
equipment. Do not place any
other equipment on top of the NetPath 100.
To Wall-Mount or Rack-Mount the NetPath 100, follow the instructions supplied with
the Wall or Rack mount adapter.
