Zhone 100 - PVC Statistics Summary Modes

5 Diagnostics
980-001-0210G NetPath 100 User’s Manual - Installation Guide 5-13
June
1999
PVC Statistics
Summary
The PVC Statistics Summary screen provides summary performance information and
access to detailed performance history displays for the Frame Relay Traffic on a per-
PVC basis.
The PVC Statistics Summary screen is accessed from the System View screen, select-
ing [PS] by typing “PS” followed by ENTER.
The PVC Statistics Summary screen, in Packet Mode, is shown in Figure 5-9.
Fi
g
ure 5-9 PVC Statistics Summar
y
Screen (Packet Mode)
Mode [M=] - Selects one of the listed options for displaying information.
First DLCI - Defines the lowest number DLCI to be displayed on the screen.
Current Interval Count - Displays “n” of “m” seconds, where “n” indicates the num-
ber of elapsed seconds in the current interval, and “m” indicates the total number of
seconds per interval (set on the PVC Performance Configuration Screen). Current in-
terval statistics are total counts for each parameter within the current interval.
NOTES: Rx - Indicates traffic received from the Frame Relay Network.
Tx - Indicates traffic sent toward the Frame Relay Network.
HUB DLCI - Tx statistics (Pkts, Octs, etc...) for a “Hub DLCI” will al-
ways be 0 (zero). This applies to a unit configured as a Tunneled Man-
agement Hub.
**************************** PVC Statistics Summary ****************************
Name: F243802 Mode[M=P,O,TC,RC,TL,RL,FD,orND]:Pkt
(P=Pkt,O=Oct,TC=TxCir,RC=RxCir,TL=TxLoss,RL=RxLoss,FD=FullDlay,orND=NetwDlay)
First DLCI [P=#]: 16 Current Interval Count: 455 of 900 secs Delay(mS)
DLCI RxPkts TxPkts BECN FECN RxDE TxDE Avg Max
25 0 0 0 0 0 0 55 70
33 0 0 0 0 0 0 55 70
234 0 0 0 0 0 0 55 70
341 0 0 0 0 0 0 55 70
464 0 0 0 0 0 0 55 70
531 0 0 0 0 0 0 55 70
793 0 0 0 0 0 0 55 70
795 0 0 0 0 0 0 55 70
942 0 0 0 0 0 0 55 70
Etc 0 0 0 0 0 0
Sum 0 0 0 0 0 0
-- 15 Min Interval History: 96 Valid -- Past Summary for DLCI [D=#orSum]: Sum --
RxPkts TxPkts BECN FECN RxDE TxDE
10 Second: 0 0 0 0 0 0
History: 0 0 0 0 0 0
ResetStats[RS] ViewHistory[VH current_time(optional)]
Help[?] Close[X] NextPage[+] AutoUpdate[AU]
>
