Zhone 100 - Figure 6-9 MLPPP TRACE

6 Options
6-24 NetPath 100 User’s Manual - Installation Guide 980-001-0210G
June
1999
Initiate an On-Demand ML-PPP connection, and a sequence of messages similar to
those shown in Figure 6-9 will be displayed as the connection is established.
Figure 6-9 MLPPP TRACE
OCP-ISDN>DIAG
Entering Diagnostic Mode - Press Esc to go back to OCP Mode
OCP-ISDN>
User : LCP: Phase is Establishing
Netw/0: LCP: Phase is Establishing
User : LCP: Timer Expired
Netw/0: LCP: Timer Expired
User : LCP: Received CONFIG REQ
User : LCP: MagicNumber 3a126c8
Netw/0: LCP: Sent CONFG REQ
Netw/0: LCP: MRU 1500
Netw/0: LCP: MagicNumber 9fbf2
Netw/0: LCP: MRRU 1500
Netw/0: LCP: EndpointDisc Local/59511
Netw/0: LCP: Received CONFIG REQ
Netw/0: LCP: AuthProto PAP
Netw/0: LCP: MagicNumber 158ada97
Netw/0: LCP: MRRU 1524
Netw/0: LCP: EndpointDisc Type/# = 1/Router6
User : LCP: Sent CONFIG REQ
User : LCP MRU 1524
User : LCP: AuthProto PAP
User : LCP: MagicNumber 9fbfa
Netw/0: LCP: Received CONFIG ACK
User : LCP: Received CONFIG ACK
User : LCP: Received CONFIG REQ
User : LCP: MagicNumber 3a1260c8
User : LCP: Sent CONFIG ACK
User : LCP: State is Open
User : PAP: Received AUTHENTICATE REQ
Netw/0: MP MP Bundle is Establishing
Netw/0: LCP: Sent CONFIG ACK
Netw/0: LCP: State is Open
Netw/0: PAP: Phase is Authenticating
User : LCP Received ECHO REQ
User : LCP: Sent ECHO REPLY
Netw/0: PAP: Timer Expired
Netw/0: LCP Received ECHO REQ
Netw/0: LCP: Sent ECHO REPLY
User : PAP: Received AUTHENTICATE REQ
Netw/0: PAP: Forwarded AUTHENTICATE REQ
Netw/0: PAP: Received AUTHENTICATE ACK
User : PAP: Forwarded AUTHENTICATE ACK
User : PAP: Authentication Phase Complete
User : NCP: Phase is Establishing
Netw/0: PAP: Authentication Phase Complete
Netw/0: MP: MP Bundle Established
