4 Operation
980-001-0210G NetPath 100 User’s Manual - Installation Guide 4-27
June
1999
Protocol Monitor
Configuration
The Protocol Monitor Configuration Screen allows you to view and alter parameters
for Protocol Monitor operations.
The Protocol Monitor Configuration Screen is shown in Figure 4-13.
Fi
ure 4-13 Protocol Monitor Confi
uration Screen
1. Percentage of Sorting Resources Required - Displays the percentage of sorting
logic needed to support the currently displayed Protocol selections.
2. Protocols - Selects up to seven protocols to be monitored, from the protocol list
displayed. All protocols to be monitored must be entered with a single command.
Can be selected individually, in a range, or group. Selected items are bracketed by
“>>”.....”<<“ characters as shown in item #1 on the example screen above.
Parenthesis indicate the subset under which a protocol is grouped, such as SNAP
(Refer to the Device Configuration Screen on page 14 in this section of this
manual, for encapsulation details).
NOTE: Additional protocols will not be added if the current value for Percentage of
Sorting Resources Required exceeds 100%. The command will be rejected when the
“Save” command is issued, and an error message will be displayed on the screen.
Commands:
Help [?] - Advances to “Help” for PVC Performance Configuration screen.
Save [SA] - Saves parameters and returns to System View screen.
Cancel [X] - Returns to System View screen without saving changes.
Save the Protocol Monitor Configuration changes when they are all set correctly by en-
tering “SA” followed by ENTER. Also returns the user to the System View screen.
************************ Protocol Monitor Configuration ************************
Name: F@43802
Percentage of Sorting Resources Required: 37.93 %
Protocols [P=] ([P=m,n,...r] and/or [P=m-n] for up to 7 selections)
>> 1) IP<< >>11) APPLETALK(SNAP)<< 21) DECNET(Raw)
2) IP/TCP >>12) DECNET(SNAP)<< 22) VINES(Raw)
3) IP/TCP/TELNET 13) VINES(SNAP) 23) XNS(Raw)
4) IP/TCP/FTP 14) XNS(SNAP) 24) IP/TCP/HTTP
5) IP/UDP 15) ISO CLNP(IETF) 25) IP/TCP/GOPHER
6) IP/UDP/SNMP 16) IP/ICMP
>> 7) IPX(SNAP)<< 17) IP/TCP/SMTP
8) IPX/SPX(SNAP) 18) IPX(Raw)
>> 9) NETBIOS(SNAP)<< 19) IPX/SPX/(Raw)
>>10) SNA(SNAP)<< 20) APPLETALK(Raw)
Help[?] Save[SA] Cancel[X]
>
