Zhone 100 - Table 3-8 AUX 1 Pinout, 8 Pin Modular Connector; Table 3-9 AUX 2 Pinout, 8 Pin Modular Connector

3 Installation
980-001-0210G NetPath 100 User’s Manual - Installation Guide 3-13
June
1999
The AUX 1 and AUX 2 Port pinouts are shown in Table 3-8 and Table 3-9.
.
In addition to providing an EIA-232 Auxiliary Port, AUX 2 also provides a local con-
sole connection to the Base module or Option Adapter.
Table 3-8 AUX 1 Pinout, 8 Pin Modular Connector
Pin Signal Direction
1CTS Output
2 DSR* Output
3 RxD Output
4SG Sig. Gnd
5 No Connection N/A
6 TxD Input
7 DTR Input
8 RTS Input
NOTES: Electrical Interface = EIA-232
*DSR is used to drive both RLSD and DSR leads within the adapter.
Table 3-9 AUX 2 Pinout, 8 Pin Modular Connector
Pin Signal Direction
1CTS Output
2 DSR* Output
3 RxD Output
4SG Sig. Gnd
5 Console Input
6 TxD Input
7 DTR Input
8RTS N/A
NOTES: Electrical Interface = EIA-232
*DSR is used to drive both RLSD and DSR leads within the adapter.
CAUTION:
Pin 8 is not used. If the unit senses a signal on this pin, “Improper
Aux 2 Cable” will be displayed in the “Test/Fault” Field on the System
View and CSU Statistics Summary Screens, and the “READY” LED
on the front panel will flash OFF every 5 seconds. These indications
are reset by the “ResetTest” command on the Device Test Screen or
through a power-up reset /self-test of the unit.
18
AUX
Conn.
18
AUX
Conn.
