Zhone 100 - Frame Manager Statistics History; Figure 5-8 Frame Manager Statistics History Screen

5 Diagnostics
5-12 NetPath 100 User’s Manual - Installation Guide 980-001-0210G
June
1999
Frame Manager
Statistics
History
The Frame Manager Statistics History screen displays all performance parameters for
the Frame Manager for each of the 96 possible, 15-minute intervals.
The first history screen (1 of up to 6) is accessed by selecting ViewHistory [VH] from
the Frame Manager Statistics Summary screen.
The first page of the Frame Manager History screen is shown in Figure 5-8.
Fi
g
ure 5-8 Frame Mana
g
er Statistics Histor
y
Screen
Page [P=] - Selects the desired History page.
Network and User statistics are as described for the previous screen
(Frame Manager Statistics Summary).
Interval “1” shows the statistics for the most recently completed interval of the
previous 24 hours.
The interval can be displayed as time-of-day rather than a simple count of intervals by
including the “current_time” parameter with the command to enter this screen, as de-
scribed on the previous page of this manual.
*********************** Frame Manager Statistics History ***********************
Name: F@43802
Page [P=#]: 1 of 6
Past ---- Network ---- ----- User -----
Int. LTO LFE DFES LTO LFE DFES
1 0 0 0 0 0 0
2 0 0 0 0 0 0
3 0 0 0 0 0 0
4 0 0 0 0 0 0
5 0 0 0 0 0 0
6 0 0 0 0 0 0
7 0 0 0 0 0 0
8 0 0 0 0 0 0
9 0 0 0 0 0 0
10 0 0 0 0 0 0
11 0 0 0 0 0 0
12 0 0 0 0 0 0
13 0 0 0 0 0 0
14 0 0 0 0 0 0
15 0 0 0 0 0 0
16 0 0 0 0 0 0
Help[?] Close[X]
>
