Frame Manager
Statistics
Summary
The Frame Manager Statistics Summary screen provides summary performance infor-
mation and access to detailed performance history displays for general Frame Relay
Traffic.
The Frame Manager Statistics Summary screen is accessed from the System View
screen, selecting [FS] by typing “FS” followed by ENTER.
The Frame Manager Statistics Summary screen is shown in Figure 5-7.
Fi
g
ure 5-7 Frame Mana
g
er Statistics Summar
y
Screen
System
Test / Fault: Highest priority Test or Fault causing disruption of the data path.
High Speed Interface Status -
DTR: State of DTR lead, when Power is being detected from the DTE.
States are: ON, OFF or (blank) if Power OFF.
RTS: State of RTS lead, when Power is being detected from the DTE.
States are: ON, OFF or (blank) if Power OFF.
Power: ON or OFF based on sensing voltage on Tx data lead(s) from the DTE
Current Interval Count: - Displays the number of seconds that have elapsed
in the current 15-minute interval.
24Hr Interval Count: - Displays the number of 15-minute intervals that have been ac-
cumulated since the last reset of the counters (max. of 96).
*********************** Frame Manager Statistics Summary ***********************
Name: F@43802
System High Speed Interface Status
Test/Fault: DTR: On
RTS: On
Power: On
Current Interval Count: 455 secs
24 Hour Interval Count: 96 Valid
---- Network ---- ----- User ------
LTO LFE DFES LTO LFE DFES
Current 0 0 0 0 0 0
24 Hour 0 0 0 0 0 0
ResetStats[RS] ViewHistory[VH current_time(optional)]
Help[?] Close[X] AutoUpdate[AU]
>
