Zhone 100 - Table 1-15 Test;Bkp (DSX

Appendix
980-001-0210G NetPath 100 User’s Manual - Installation Guide A-17
June
1999
Test/BKP
(DSX)
Test/BKP shows the highest priority CSU or DSX related test or Backup (ISDN) con-
dition currently detected. This is displayed on the CSU/DSX Statistics Summary
screen when in DSX Mode.
Table 1-15 Test/BKP
(DSX)
Displa
y
Description
Mgmt Line Netw Operator initiated Full T1 Line loopback in place at Network Port toward Network
Circuit.
Mgmt Pyld Netw Operator initiated Full T1 Payload loopback in place toward Network Circuit.
Mgmt QRSS Netw Operator initiated QRSS pattern BERT is being sent toward the Network Circuit.
Mgmt Alt1 Netw Operator initiated Alternating Ones pattern BERT is being sent toward the Network
Circuit.
Mgmt 2047 Netw Operator initiated 2047 pattern BERT is being sent toward the Network Circuit.
Mgmt Zero Netw Operator initiated All Zeros pattern BERT is being sent toward the Network Circuit.
Mgmt Loop Cpe Operator initiated Full T1 Line Loopback applied within the unit’s framer toward the
CPE port(s): User Port (also DSX Port and Drop Port if DSX/Drop Adapter installed.)
Mgmt Send Lp Up Operator initiated T1 Line Loop Up code sent toward the Network.
Mgmt Send Lp Dn Operator initiated T1 Line Loop Down code sent toward the Network.
Netw Set Line Externally initiated (Network sent code) Full T1 Line loopback in place at Network
Port toward Network Circuit.
Netw Set Payld Externally initiated (Network sent code) Full T1 Payload loopback in place toward
Network Circuit.
Dsx Loop Netw Operator initiated Loopback is in place at the DSX Port (for DS0s assigned to DSX
Port @ Nx64K) toward the Network Circuit.
Dsx 2047 Netw Operator initiated 2047 pattern BERT is being sent toward the Network Circuit (for
DS0s assigned to DSX Port @ Nx56K.)
Dsx Zero Netw Operator initiated All Zeros pattern BERT is being sent toward the Network Circuit
(for DS0s assigned to DSX Port @ Nx56K.)
Dsx Line Dsx Operator initiated Full T1 Line Loopback in place toward the DSX Circuit.
Dsx Pyld Dsx Operator initiated Full T1 Payload loopback in place toward the DSX Circuit.
Dsx QRSS Dsx Operator initiated Full T1 QRSS pattern BERT is being sent toward the DSX Circuit.
Dsx 2047 Dsx Operator initiated 2047 pattern BERT is being sent toward the DSX Circuit.
