3 Installation
3-16 NetPath 100 User’s Manual - Installation Guide 980-001-0210G
June
1999
Power Control
Unit
Specifications
Table 3-12 Model 467 Power Control Unit General Specifications
Item Description
Dimensions 2.5" H x 7.25" W x 4.6" D
Weight As packaged including carton: 4.5 lbs.
Unit alone: 3.5 lbs.
Operating Range Temperature: 0 to 50 degrees C. operating.
Relative Humidity: 5 to 95% non-condensing.
Altitude: 10,000 ft. max. operating,
50,000 ft. max. non-operating.
Shock and Vibration: As normally encountered during shipping and handling.
Power Requirements AC Input: 125 VAC, 50 - 60 Hz, 0.22A for the internal power transformer in
addition to the connected device.
7-foot cord with 3-prong plug.
Switched AC Output: 125 VAC, 5 AMPS max.
1-foot cord with 3-prong receptacle.
Power Output: 22 VAC, 30 VA (NetPath 64 Only).
Power/Control Cable: 4-conductor, with 4-pin keyed locking connector, 7 ft. length.
Regulatory Compliance UL - 1950
