Device
Status / Test
The Device Status / Test screen provides base module status and access to system tests.
The Device Status / Test screen is shown in Figure 5-2.
Fi
g
ure 5-3 CSU Test Screen
CSU Fault - Displays current status being detected by CSU.
States (in highest priority order) are:
CSU Fault - Detected internal failure of unit’s CSU.
CFA/RED Alarm - Detected loss of T1 facility.
Remote/Yellow Alarm - Carrier alarm notification that Transmit failure from this
DCE has been detected on this T1 facility.
AIS/Blue Alarm - Carrier alarm notification that an upstream signal failure has
been detected on this T1 facility.
CSU Threshold Alarm - Link Error Threshold reached or exceeded.
(blank) - No failures or errors detected.
Netw Set Loop - Displays current telco-initiated loop condition.
States are: “Line Lp to Netw,” “Payld Lp to Netw,” “V.54 Lp to Netw” or
(blank) if none.
Frame Mgr Fault - Displays current condition of Frame Manager traffic when appli-
cable. States are:
Clear Channel - Frame Manager configured for and operating in “Transparent”
mode.
LMI Network Failure - Invalid or no response to LMI Status enquiries toward
Network.
LMI User Failure - Invalid or no LMI Status requests from User equipment.
***************************** Device Status / Test *****************************
Name: F@43802
CSU Fault: T1 ID: NONAME
Netw Set Loop:
Test Mode [T=]
1) Clear Frame Mgr Fault: LMI Netw Failure
2) Line Lp to Netw
3) Payld Lp to Netw High Speed Interface
4) Send LoopUp DTR: On
5) Send LoopDn RTS: On
>>6) QRSS to Netw<< Power: On
7) Alt Ones to Netw Interface: ITU-V35
8) 2047 Payld to Netw
9) 2047 Payld to User
10) Loop to User
11) Test Pkts to Netw
BERT: Blocks Sent: , , Block Errors: , , BlkErr Rate: 0.00E+00
Test Duration: 00:00:00
ResetTest[RT] InjectErr[IE secs] RebootExt[RE secs]
Help[?] Close[X] AutoUpdate[AU]
>
